IB412

  • Bronze Globe Valve, 300 SWP – 1000 WOG, Threaded Ends
  • Conforms to MSS SP-80, Type 1
  • Not Intended for Use in Potable Water
  • Non-Shock

Product Documents

IOMs

Spec Sheets

3D CAD Files

Description

Material

Bronze
ANSI/Pressure Rating

300 SWP – 1000 WOG
End Connection

Threaded
Stem Type

Rising Stem
Body Style

Straight
Bonnet Type

Union
Seat Material

Bronze
Disc Material

Bronze Regrinding
Product Size

1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2"
Valve Type

Globe Valve
Add to quote
Category:

Weights, Dimensions, and Box Quantity

Size
Unit Weight
Unit Dims.
LxWxH
Box Quantity
Box Dims.
LxWxH
1/4"
0.82
2.06 x 0.25 x 4
10
8.5 x 8.5 x 4.125
3/8"
0.8
1.06 x 0.375 x 4
20
8.5 x 8.5 x 4.125
1/2"
1.3
2.44 x 0.5 x 4.5
10
10 x 7.5 x 2.5
3/4"
2.1
2.94 x 0.75 x 5.19
6
10 x 7.5 x 2.5
1"
3.7
3.75 x 1 x 6.38
6
10.5 x 10 x 3
1-1/4"
5.3
4.25 x 1.25 x 7
4
12 x 7 x 3.5
1-1/2"
7.3
4.75 x 1.5 x 7.75
4
13.565 x 8.9375 x 4.8125
2"
11.74
5.75 x 2 x 10
2
13.565 x 8.9375 x 4.8125
